1958 Chevrolet 3100
1958 Chevrolet 3100 - Very clean custom pickup in the shop for some electrical, audio, and mechanical work.
1958 Chevrolet 3100 - Featuring a small block Chevrolet engine coupled to 700R4 transmission. Full Edelbrock carb rebuild and new balancer installation.
1958 Chevrolet 3100 - Very clean interior with leather-wrapped dash door panels and headliner. JL Audio Bluetooth adapter added to stream audio through existing head unit.
1958 Chevrolet 3100 - Fuel gauge fixed by replacing the sending unit. Sending unit upgraded from original arm style to floatless stye.
1967 Chevrolet Chevelle
1967 Chevrolet Chevelle - Super clean, low mile getting an LS7 427 7.0L Connect & Cruise Powertrain System with T56 Super Magnum Transmission.
1967 Chevrolet Chevelle - American Autowire chassis harness installation.
1967 Chevrolet Chevelle - Trunk mount battery with 1/0 main power cable, master battery switch and 400 amp MEGA fuse for protection.
1967 Chevrolet Chevelle - Direct fit Vintage Air A/C system installation.
1967 Chevrolet Chevelle - GM Performance Parts engine controller harness with upgraded F6 braided nylon sleeving.
1967 Chevrolet Chevelle - Engine bay with LS7 427 with custom engine wiring, firewall mount ECU, and dual SPAL electric fans.
1984 Dodge Ramcharger
1984 Dodge Ramcharger - Complete Holley Sniper 2 fuel injection system with Hyperspark Ignition system and upgraded fuel system.
1984 Dodge Ramcharger - Custom installed Vintage Air A/C system based on their latest Gen 5 compac evaporator.
1984 Dodge Ramcharger - Upgraded original poly tank to a new 40 gallon steel tank with Holley in-tank EFI pump and new AN PTFE fuel lines.
1984 Dodge Ramcharger - Custom 14 ga steel firewall plate and A/C hose trim cover.
1984 Dodge Ramcharger - Custom dash vent adapters design in CAD and 3D printed in ABS allow OEM look of air outlets.
1984 Dodge Ramcharger - Custom fit Vintage Air Gen 5 compac evaporator fits nicely in original location of heater box.
1967 Pontiac Firebird
1967 Pontiac Firebird - LS3/525 GM crate engine with 6 speed manual transmission. Complete vehicle wiring, Dakota Digital gauges, Vintage Air, and audio system.
1967 Pontiac Firebird - Interior wiring begins with new Painless chassis harness and Holley Terminator XMAX engine management installation.
1967 Pontiac Firebird - Vintage Air electronic HVAC controller and Retrosound head unit installation. Digital Guard Dawg push button start and electronic E-Stopp parking brake.
1967 Pontiac Firebird - Trunk mount battery wired with 1/0 main power cable, master battery switch, and Odyssey AGM battery.
1967 Pontiac Firebird - Custom TMI interior almost complete with color-matching dash, door panels, and center console.
1967 Pontiac Firebird - Custom rear package tray wrapped with red vinyl and provides rear sound stage with JL Audio 6 x 9 speakers.
1965 International Harvester
1965 IH Pickup - Getting a complete electrical system, engine management system, Vintage A/C, E-Stopp, and audio system.
1965 IH Pickup - 2019 GML8T swap with 6L80E, Atlas transfer case, Griffin radiator, and SPAL cooling fans.
1965 IH Pickup - Day one of dash and interior wiring removal.
1965 IH Pickup - Vintage Air Gen 5 evaporator box mock-up/installation.
1965 IH Pickup - New AA wire harness and Digital Guard Dawg push-button installation.
1965 IH Pickup - Main power distribution, circuit breakers and relay installation.
1967 Mustang Fastback
1967 Mustang Fastback - Complete Painless chassis harness installation, Vintage Air, electric fan, and Classic Instruments gauges being installed.
1967 Mustang Fastback - Cleaning up previous interior wiring and gauge cluster wiring.
1967 Mustang Fastback - Custom-routed HVAC lines and heater hoses behind fender.
1967 Mustang Fastback - Rewired gauges, Vintage Air HVAC, and added Dakota Digital fan controller.
1967 Mustang Fastback - Hidden circuit breakers for fan and Vintage Air along with Painless main fuse under battery tray.
1967 Mustang Fastback - New horns, A/C dryer, and all front light wiring completed.
1957 Chevrolet 210
1957 Chevrolet 210 - Final electrical review, Holley Sniper setup, and initial engine start.
1957 Chevrolet 210 - 383 small block Chevy, Holley Sniper fuel injection, Tremec 5-speed, March front accessory drive, and lots of polished chrome!
1957 Chevrolet 210 - Complete Vintage Air installed along with Holley Sniper handheld mounted in the glove box.
1957 Chevrolet 210 - Dakota Digital VHX gauges retrofitted in original dash bezel.
1957 Chevrolet 210 - Dakota Digital VHX gauge controller installed behind cluster.
1957 Chevrolet 210 - Reproduction Chevrolet Wonderbar AM/FM Bluetooth head unit installed.
1986 Chevrolet K10
1986 Chevrolet K10 – Extensive completion of truck including front lighting/grille style, all fluid systems, complete electrical system, air conditioning installation, and full interior assembly.
1986 Chevrolet K10 – 496 Big Block Chevrolet stroker, Turbo 400 transmission, March front accessory drive, Hydroboost braking system installed.
1986 Chevrolet K10 – Complete interior assembly/installation. All new dash components, rebuilt steering column, new Autometer gauges, and Restrosound stereo.
1986 Chevrolet K10 – New carpet installed along with all new interior trim panels and kick panels.
1986 Chevrolet K10 – New door components, weatherstrip, glass, mirrors, and vent window assemblies installed.
1986 Chevrolet K10 – Dynamat Extreme installed on floor, cab walls, and firewall.
Déjà vu Red 1962 Chevrolet Bel Air
Another 1962 Chevrolet Bel Air - 409 Big Block Chevrolet with 4-speed transmission and dual quad Holley Sniper EFI.
Another 1962 Chevrolet Bel Air - Dual quad Holley Sniper EFI being installed under factory air cleaner.
Another 1962 Chevrolet Bel Air - Initial interior disassembly and dashboard removal.
Another 1962 Chevrolet Bel Air - Dakota Digital HDX gauges, Vintage Air, and Classic Autosound head unit being installed.
Another 1962 Chevrolet Bel Air - Final interior assembly and seat installation.
Another 1962 Chevrolet Bel Air - JL Audio amplifier, 10" subwoofer, and rear speaker components.
1962 Silver Chevrolet Bel Air
1962 Chevrolet Bel Air - 409 Big Block Chevrolet with 4-speed transmission and dual quad Holley Sniper EFI.
1962 Chevrolet Bel Air - Dual quad Holley Sniper EFI installed for a factory look.
1962 Chevrolet Bel Air - Final interior assembly and seat installation.
1962 Chevrolet Bel Air - Dakota Digital HDX gauges, Vintage Air, and Classic Autosound head unit installed.
1962 Chevrolet Bel Air - American Autowire chassis harness installation.
1962 Chevrolet Bel Air - Custom fabricated main power center at battery.
1969 Chevrolet Camaro LS7
1969 Chevrolet Camaro - Arrived at the shop for new engine management controller and upgrades.
1969 Chevrolet Camaro - Freshly installed Borowski LS7 engine.
1969 Chevrolet Camaro - Haltech FT550 ECU and harness ready for installation.
1969 Chevrolet Camaro - New head unit, keyless ignition, and master battery switch to be installed.
1969 Chevrolet Camaro - New Haltech harness and dash rewiring underway.
1969 Chevrolet Camaro - High-current power center installed behind glove box.
1978 Pontiac Trans Am
1978 Trans Am - Ground up restoration with custom paint, all new front/rear suspension, complete wiring from end to end, and hand painted bird on the hood by Joe Martin.
1978 Trans Am – GM Connect & Cruise engine/transmission, custom snowflake wheels, American Autowire chassis harness, full power electronics, audio, and security system.
1978 Trans Am - GM supercharged LT4 engine and 4 speed overdrive transmission.
1978 Trans Am - Engine ECU, main power distribution center and fuse box mounted on firewall. 1/0 main power cable running to rear for trunk-mounted battery.
1978 Trans Am - All new interior components, gen 5 Vintage Air, Custom Autosound head unit, and kick panel speakers. New relic power windows and power door locks installed.
1978 Trans Am - Custom carbon fiber dash bezel, Dakota Digital gauges, Dakota Digital electronic shift indicator, Dakota Digital BIM interface module.
1975 Ford Bronco
1975 Ford Bronco - new body, Kincer chassis, Ford Coyote 5.0, 10-speed transmission. Complete custom electrical system and all accessories installed.
1975 Ford Bronco - NOS style LED headlights and turn signals installed.
1975 Ford Bronco - Ford Coyote 5.0 crate engine. Engine compartment is complete and all wiring is hidden from view.
1975 Ford Bronco - all new suspension, front/rear axles, and hardware.
1975 Ford Bronco - Atlas transfer case and driveshafts. Amp research power steps installed.
1975 Ford Bronco - Ford performance power distribution box installed inside glove compartment.
Previous Projects - Vehicles
2008 Jeep JK - electrical system upgrades, wiring clean-up, and new power cable fabrication.
2008 Jeep JK - installation of main and aux battery power distribution blocks.
2008 Jeep JK - new high current AMG fuse blocks and custom fabricated power/ground cables.
2008 Jeep JK - dash upgraded to 2011 style interior.
2008 Jeep JK - 2011 body harness getting re-worked to delete all unused circuits and add new circuits for ARB compressors under each seat - before.
2008 Jeep JK - 2011 body harness getting re-worked to delete all unused circuits and add new circuits for ARB compressors under each seat - after.
Previous Projects - ATV/SSV
Can-Am Maverick Sport - Soundbar, Bluetooth controller, and 6.5" roll cage speaker install
Can-Am Maverick Sport - NS27A 27" 200 watt NavAtlas soundbar install
Can-Am Maverick Sport - NT650AT 6.5” amplified roll-cage speaker install
Club Car golf cart - RGBW rock light install
Club Car golf cart - RGBW rock light install
Club Car golf cart - RGBW rock light install
Current Projects - Boats
Custom Airboat - Chevrolet LS engine with Holley Terminator X.
Custom Airboat - Existing dual battery setup with wingnut style battery terminals and undersized cables.
Custom Airboat - Custom 2 gauge marine-rated battery cables installed at battery switch.
Custom Airboat - New battery terminals installed, all accessory circuits ran to power distribution block.
Custom Airboat - Master battery switch wired for correct operation.
Previous Projects - Boats
2001 Viking 47 - new Fusion multi-zone head unit, 10-channels of amplifier upgrades, and Bazooka subwoofer installation.
2001 Viking 47 - existing JBL controller removed and helm modified for new Fusion head unit.
2001 Viking 47 - new Fusion head unit installed at helm on flybridge.
2001 Viking 47 - new Poly Planer 6.5" coaxial speakers added at front of flybridge.
2001 Viking 47 - two 8" Bazooka tubes mounted under gunnels.
2001 Viking 47 - existing JBL controller and JBL amplifier removed.
Previous Projects
2009 Chevrolet G3500 Skoolie - complete 12 volt and 110 volt electrical system design and installation
2009 Chevrolet G3500 Skoolie - 9,000 BTU Ductless Mini Split Air Conditioner and dual propane tanks
2009 Chevrolet G3500 Skoolie - Framework for Victron MultiPlus 12/3000 Inverter/Charger, electrical center and Kilovault HLX3600 12V 300Ah Battery
2009 Chevrolet G3500 Skoolie - Framework for shower, dinette, stove, sink, and fridge
2009 Chevrolet G3500 Skoolie - Framework for storage, initial wiring in front of bus
2009 Chevrolet G3500 Skoolie - Audio system front speakers, LED overhead lighting being installed
